Section 5, User Interface - Menu Descriptions
61179605L5-5B 5-29
The Previous Ethernet Statistics menu fields are described in Table 5-19 .
The Current Ethernet Statistics menu hot keys are shown in Table 5-20 .
Table 5-19. Ethernet Statistics - Previous Fields
Field Description
Successful Tx Packets This field displays the number of packets successfully
transmitted from the unit.
Errored Tx Packets This field displays the number of packets transmitted with
errors from the unit.
Successful Rx Packets This field displays the number of packets successfully received
to the unit.
Errored Rx Packets This field displays the number of packets received with errors to
the unit.
Broadcast Rx Packets This field displays the number of packets received by the layer
addressed as broadcast.
Multicast Rx Packets This field displays the number of packets received by the layer
addressed as multicast.
Rx CRC Errors This field displays the number of Cyclic Redundancy Check
(CRC) errors received to unit.
Table 5-20. Current Ethernet Statistics Menu Hot Keys
Hot Key Description
C
This hot key is used to clear the previous Ethernet statistics.
J
This hot key displays the “Current Ethernet Statistics Menu” on page 5-26.
