Total Access 1240 Installation and Maintenance Practice
5-84
61179605L5-5B
SHDSL Loop 1 Local Loopback Menu
The SHDSL Loop 1 Local Loopback menu (see
), is used to perform and view local
loopback tests. For troubleshooting purposes, the Total Access 1240 provides three types of
local loopbacks:
• Dual-Sided
• Customer
• Network
Figure 5-63. SHDSL Loop 1 Local Loopback Menu
The SHDSL Loop 1 Local Loopback menu options are shown in
.
Table 5-59. SHDSL Loop 1 Loopback Menu Options
Option
Description
Function
1
Dual-Sided
This option is used to initiate a dual-sided loopback. For
more information, refer to
2
Customer
This option is used to initiate a customer side loopback.
For more information, refer to
3
Network
This option is used to initiate a network side loopback.
For more information, refer to
09/01/05 03:05
Total Access 1240
SHDSL Loop 1 Local Loopback
1. Dual-Sided
2. Customer
3. Network
Selection:
'N' - Next Loop 'P' - Prev Loop 'S' - Select Loop '?' - System Help
