Section 5, User Interface - Menu Descriptions
61179605L5-5B 5-71
SHDSL Loop 1 Provisioning Menu
The SHDSL Loop 1 Provisioning menu (see
Figure 5-51 ) is used to provision all of the SHDSL
Circuit IDs. A Circuit ID is initially named using the SHDSL Loop 1 Service State Menu option
from the Bridge Port Summary Screen menu.
Figure 5-51. SHDSL Loop 1 Provisioning Menu
The SHDSL Loop 1 Provisioning menu options available are shown in Table 5-51 .
Table 5-51. SHDSL Loop 1 Provisioning Menu Options
Option Description Function
1 Service State This option displays the “SHDSL Loop 1 Service State
Menu” on page 5-72.
2 Interface Mode This option displays the “SHDSL Loop 1 Interface Mode
Menu” on page 5-73.
3 Rate This option displays the “SHDSL Loop 1 Rate Screen” on
page 5-74.
4 G.991.2 Annex This option displays the “SHDSL Loop 1 G.991.2 Annex
Menu” on page 5-75.
5 Lineprobing (PMMS) This option displays the “SHDSL Loop 1 LineProbing
Menu” on page 5-76.
6 PMMS Margin This option displays the “SHDSL Loop 1 PMMS Margin
Screen” on page 5-77.
7 Loopback Timeout This option is used to enable or disable loopbacks. If
enabled, the timeout can be set from 1–99 minutes.
8 Alarm Thresholds This option displays the “SHDSL Loop 1 LineProbing
Menu” on page 5-76.
09/01/05 01:34
Total Access 1240
SHDSL Loop 1 Provisioning
1. Service State : OOS-Maintenance
2. Interface Mode : 2-wire
3. Rate : 2304 Kbps (N=36)
4. G.991.2 Annex : B
5. Lineprobing (PMMS) : Disabled
6. PMMS Margin : N/A
7. Loopback Timeout : Disabled
8. Alarm Thresholds
Selection:
'N' - Next Loop 'P' - Prev Loop 'S' - Select Loop '?' - System Help
