Accessories and Replacement Parts
Mfr. Part No. Code Description
6205-0002 159 000 858 1-meter length DIN Rail
6205-0003 159 000 859 End clip for DIN Rail
DIN rail in one meter (1000 mm) lengths, and DIN rail clips are available. The standard packaging of these power
supplies are to be fastened to DIN rails, and accessory clips will keep the supplies from sliding if the rail itself is
mounted vertically, for example. Contact the factory for more details.
External Relay
Signet 8059
External Relay Modules
Electromagnetic
Sensor
Passive Relays
and Outputs
Signet Sensors
2551 2552
7310 Switching Power Supplies
Signet sensors
Sys
tem Ov
erview
Signet Instruments
8350 8450
8900 9900
All sold separately
Signet Instruments
8350 8450
8900 9900
with 8050 Universal Mount Kit
Integral Mount Panel Mount
ENTER
Signet Instruments
8350 8450
8900 9900
with 8052 Integral Mount Kit Signet 8900
Multi-Parameter
Controller
Field Mount - Pipe, Tank, Wall
+ +
NC COM NO RELAY A NC COM NO RELAY B NC COM NO RELAY C NC COM NO RELAY D
DC OUTPUT + - DC INPUT - + + S3L - + S3L - INPUT PASS-THRU
COM
POWER
Signet 3-8059 Relay Module Test A
Test B
Test C
Test D
Relay A
Relay B
Relay C
Relay D LISTED E171559 ®
FLOW
Ordering Information
Mfr. Part No. Code Voltage and Current Output Options
7310-1024 159 873 004 24 VDC Power Supply, 10W, 0.42 A
7310-2024 159 873 005 24 VDC Power Supply, 24W, 1.0 A
7310-4024 159 873 006 24 VDC Power Supply, 40W, 1.7 A
7310-6024 159 873 007 24 VDC Power Supply, 60W, 2.5 A
7310-7024 159 873 008 24 VDC Power Supply, 96W, 4.0 A
3-7310.099 Rev A (03/13)
