6.4.6. K factors (in pulse/litre) for saddles
When the dimensions of the pipe are slightly different from dimensions d and s given in the table, recalculate the K factor using one of
the formulae in chap. 6.4.2.
If the measuring device does not automatically convert the K factor, use the following conversion formulae before setting the para-
meters of the device:
• K factor in pulse/US gallon = K factor in pulse/litre x 3.785
• K factor in pulse/UK gallon = K factor in pulse/litre x 4.546
Table 19: K factors, external diameters and theoretical cross-sections of saddles
measuring device
inserted
8020, 8024, 8025, 8026
8041, 8045
external diameters and theoretical cross-sections
material of the pipe
pVc
pe / pp
pVc
pe / pp
d
pVc
[mm]
s
pVc
[mm]
d
pp
[mm]
s
pp
[mm]
dn
50
14,2 (L)
15,6 (L)
10,4 (L)
9,28 (L)
63
4,7
63
5,8
65
11,2 (L)
12,3 (L)
14,5 (L)
12,9 (L)
75
5,5
75
6,9
80
7,37 (L)
7,80 (L)
21,3 (L)
20,4 (L)
90
6,6
90
8,2
100
4,83 (L)
5,29 (L)
33,0 (L)
30,4 (L)
110
8,1
110
10
110
3,45 (L)
-
44,7 (L)
-
125
9,2
-
-
125
2,55 (L)
3,10 (L)
63,7 (L)
52,1 (L)
140
10,3
140
12,8
150
1,67 (L)
2,03 (L)
137 (L)
78,8 (L)
160
6,2
160
14,6
180
1,08 (L)
1,37 (L)
197 (L)
116 (L)
200
9,6
200
18,2
200
0,80 (L)
1,07 (L)
290 (L)
147 (L)
225
8,6
225
20,5
(L): long sensor version
