8644/phoenix - 13
I
NSTALLATION
/ C
OMMISSIONING
Elektrical installation
You can find information regarding the electrical installation:
- in the Phoenix Contact handbook Interbus - Inline IB IL SYS PRO UM
- or in the System Description chapter, Paragraph Field Bus Nodes Profibus DP
bar
Switch on the pressure supply.
Only then switch on the voltage!
Fluidic commissioning
Check the connections, voltage and operating pressure!
Make sure that the max. operating data (see rating plate) are not exceeded!
Check allocation according to instructions of ports 1 and 3 or 5: these shall under no circumstances be
swapped!
For electrical operation, unlock the manual override!
Measures to be taken before fluidic initialization
Fluidic commissioning
Electrical commissioning
You can find information regarding the electrical initialization:
- in the Phoenix Contact handbook Interbus - Inline IB IL SYS PRO UM
- or in the System Description chapter, Paragraph Field Bus Nodes Profibus DP
