Brooks Instrument Model 5866 Pressure Controller
1-8
Power Requirements
N.C. 3.5 watts; +15 Vdc (±5%) @ 35 mA, -15 Vdc (±5%) @ 180 mA
N.O. 10.5 watts, ±15 Vdc (±5%) @ 350 mA
Class III Equipment: The dc Mains input shall be supplied from a SELV
(Separated Extra-Low Voltage) source.
Output Signals
Standard: 0-5 Vdc min load resistance 1 k ohm
Optional: 0-10 Vdc min load resistance 2 k ohm, 0 or 4-20 mA into
maximum 500 ohm
5 Volt Reference Output
5 Volts ±0.2% min Load 1 k ohms.
Pressure Setpoint Signals
Standard: 0-5 Vdc input (impedance 1M ohm)
Optional: 0-10 Vdc input (impedance 1M ohm), 0 or 4-20 mA input
(impedance 250 ohm)
Remote Pressure Sensor Input
Standard: 0-5 Vdc input (impedance 1M ohm)
Optional: 0-10 Vdc input (impedance 1M ohm)
Dimensions
Refer to Figure 1-4
Valve Type
Standard: Normally Closed
Optional: Normally Open
Process Connections
Standard: 1/4" stainless steel compression fittings
Optional: 1/4" VCR TM , 1/4" VCO TM , 1/8" compression
Electrical Connection
15 pin D-Connector (DA-15P)
Environmental Conditions
Installation Category: “I”
Pollution Degree: 2
Humidity: 50-80% Relative Humidity
Meter Altitude: 6562 feet (2,000 meters)
For Indoor Use ONLY
Mains supply voltage fluctuations not to exceed ±10% of the nominal voltage
Environmental Effects
EMC EffectsMeets the requirement of the EMC directive
(89/336/EEC) EN 61000-4-2 thru 4-8
PED Sound Engineering Practice (SEP)
Area classifcation and certification
Area Certified for use in hazardous areas in Europe
II 3 G EEx nA II T4
KEMA 03ATEX1532 X
Per EN 60079-15:2003
The modules shall be installed in a suitable enclosure providing a degree of
protection of at least IP54 according to EN 60529, taking into account the
environmental conditions under which the equipment will be used.
