Page 48
Rev. 01/11
-3.14-
MFX
ADDRESS
Each MFX connected on the communications bus must have an
unique address number assigned. Address 127 is a universal
address that will result in all MFX instruments on the network
responding simultaneously
—regardless of address—resulting in
CRC errors. Only select address location 127 if one meter is on the
network.
ISO-MOD DATALOGGER (Value)
LOGGING
INTERVAL
From the OUTPUT 1 menu, select the time INTERVAL between
readings. INTERVAL values between 1 and 30,000 seconds are
acceptable.
For reference there are:
60 seconds in 1 minute
300 seconds in 5 minutes
1,800 seconds in 30 minutes
3,600 seconds in 1 hour
30,000 seconds in 8.33 hours
Table 3.6 describes some typical configurations of the INTERVAL
and DURATION times with what the expected data samples
collected count will be.
PART 3 - KEYPAD CONFIGURATION
Data Logger
Option
Example No.
INTERVAL
Seconds
DURATION
Hours
Operated
Samples
Collected
1
1
24 (1 day)
86,400
2
10
168 (7 days)
60,480
3
60 (1min)
720 (30 days)
43,200
4
300 (5 min)
8,760 (1 yr)
105,120
5
1,800 (30 min)
8,760 (1 yr)
17,520
6
3,600 (1 hr)
8,760 (1 yr)
8,760
7
18,000 (5 hr)
26,280 (3 yr)
17,520
Table 3.6 - Interval and Duration Times
