Appendix C
Cable Listings
Parallel Cable: Connect a Centronics
type 36-pin cable.
Serial Cable: Connect a cable that complies with one of the
configurations listed in the table below (the serial interface cable must
have specific connections [pin-outs] for proper data exchange). The
cable part numbers and suggested applications are included (contact a
reseller for ordering information).
Part # 32-2300-01
Part # 32-2301-01
