10 S-Class
3.2 Loading Ticket Stock
The procedure to load the printer differs depending upon the model,
options, and stock type being used. These differences are detailed below.
3.2.1 ST Models
 Note: If your printer is equipped with the Roll Hanger option but you want to
use an internal fan-fold ticket source instead, the Roll Hanger must
be removed. Remove the Roll Hanger by turning it counter-clockwise
to unscrew it from the centerplate of the printer.
To load fanfold ticket stock into a table-top printer proceed as follows:
 Plug in and turn ‘On’ the printer.
 Insert the Key into the lock and turn it, as shown, to unlock the
Access Cover.
 Raise the Access Cover (or, for convenience, the cover may be
removed by sliding it forward and then raising it up and off the
hinges).
 Perform this step according to the printer’s Media Sensor option and
the type of ticket stock being used:
