Datamax-O'Neil S-Class User Guide User Manual
Page 40
32
S-Class
Printhead Latch
Ticket Stock
Printhead Assembly
Media Sensor
Raise the Printhead Assembly and lock the Printhead Latch.
Turn ‘On’ the printer and load ticket stock; see Section 3.2.
To verify the alignment, press the FEED button several times – the
stopping point (TOF) should be the same for each ticket output.
