Datamax-O'Neil S-Class User Guide User Manual
Page 37
S-Class
29
Ticket Stock
Slide
Printhead Latch
Printhead Assembly
Media Sensor
Lower the Printhead Assembly and lock the Printhead Latch.
Turn ‘On’ the printer and load ticket stock; see Section 3.2.
Lower and lock the Access Cover.
To verify the alignment, press the FEED button several times – the
stopping point should be the same for each ticket that is output. Note
that if the Fault Indicator illuminates, the sensor needs to be
repositioned (see Section 5 for a complete listing of possible causes).
