34 S-Class
The table below lists the default settings, according to the printer model, for each Stock ID number.
Stock ID Default Settings
Print Width
Stock ID
3210 Models 3306 Models
Start of Print
Position
Cut/Tear
Position*
0 3.15" (80.0 mm) 3.20" (81.3 mm) .07" (1.8 mm) .05" (1.3 mm)
1 3.15" (80.0 mm) 3.20" (81.3 mm) 4.28" (108.7 mm) 4.26" (108.2 mm)
2 3.15" (80.0 mm) 3.20" (81.3 mm) 1.67" (42.4 mm) 1.65" (41.9 mm)
3 3.15" (80.0 mm) 3.20" (81.3 mm) .02" (.5 mm) 0
4 1.89" (48.0 mm) 1.81" (46.0 mm) .02" (.5 mm) 0
5 1.89" (48.0 mm) 1.92" (48.8 mm) 4.33" (110.0 mm) 4.30" (109.2 mm)
6 1.89" (48.0 mm) 1.92" (48.8 mm) 1.70" (43.2 mm) 1.67" (42.4 mm)
7 1.89" (48.0 mm) 1.92" (48.8 mm) 1.45" (36.8 mm) 1.42" (36.1 mm)
8 2.20" (55.9 mm) 2.24" (56.9 mm) .07" (1.8 mm) .05" (1.3 mm)
9 3.15" (80.0 mm) 3.20" (81.3 mm) 0 0
*SV Model printers using the Tear Bar must add .07 inch (1.8mm) to these distances for Top Plate clearance of the ticket.
