S-Class
11
“Standard Media Sensor” using Fan-Fold Stock –
With the ticket TOF Marks facing ‘down’ (away from you),
place the ticket stock in the bottom of the printer. (If using an
external supply, route the ticket stock into the printer through the
Rear or Bottom Slots.)
Ensure that the Printhead Latch is in the ‘Locked’ position.
Bottom Slot
Ticket Stock
Thumbscrew
Printhead Latch
Rear Slot
Unlocked
Locked
Media
Guides
