10. Versions / Order Description
Description Type Key
Reference
MHM5_
D2 B1
B - _ _
_ _-
_
_ _
_-
0CC
Interface
DeviceNet
D2
Version
B1
Code
Binary
B
Singleturn
00
Multiturn (4096 revolutions)
12
Revolutions (Bits)
Multiturn (16384 revolutions)
14
4096
12
8192
13
Steps per revolution
(Bits)
65536
16
Clamp flange
C
Synchro flange
S
Hollow shaft
B
Flange
Square flange
Q
10
10 mm
06 mm
06
Shaft diameter
15
15 mm (hollow shaft)
0
Mechanical options
Without
S
Shaft sealing (IP66)
Stainless steel version
V
Customized
C
0CC
Connection
Connection Cap
Standard = bold, further models on request
Ordering reference for a 10mm solid shaft absolute multiturn encoder :
MHM5 D2 B1 B 12 13 C 10 0 0CC : MHM510-DNET-001
Ordering reference for a 15mm blind shaft absolute multiturn encoder :
MHK5 D2 B1 B 12 13 B 15 0 0CC : MHK515-DNET-001
