DEVICE NET USER MANUAL
BEI Sensors SAS
Espace Européen de l’Entreprise
9, rue de Copenhague
B.P. 70044 Schiltigheim
F 67013 Strasbourg Cedex
Tél : +33 (0)3 88 20 80 80
Fax : +33 (0)3 88 20 87 87
Mail : [email protected]
Web : www.beisensors.com
7.2.5. Parameter Saving
Master to Absolute Rotary Encoder: Set-Parameter
CAN ID MAC ID Service Code Class ID Instance ID
Byte0 Byte1 Byte 2 Byte 3
32 23 01
If the transfer has been successful, the abso-
lute rotary encoder responds after 3-4s with
the Duplicate MAC-ID. After that the master
must reallocate the slave.
If the transfer is not successful, an error mes-
sage will be sent. The service code used to
save the parameter set is manufacturer spe-
cific.
Version 05/04 UME-OCD-D2 Page 17
