7.2.4. Preset Value
Master to Absolute Rotary Encoder:Set-Parameter
CAN ID MAC ID Fragment Service
Code Class
ID Instance
ID Attribute
ID
Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7
41C 8A 00 10 23 01 73 X X
X: desired preset value
Absolute Rotary Encoder to MasterConfirmation
CAN ID MAC ID
Byte0 Byte 1 Byte 2
41B 8A C0 00
Master to Absolute Rotary Encoder:Set-Parameter
CAN ID MAC ID Fragment
Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7
41C 8A 81 X X - - - -
X: desired preset value
Absolute Rotary Encoder to MasterConfirmation
CAN ID MAC ID
Byte0 Byte 1 Byte 2
41B 8A C1 00
Absolute Rotary Encoder to Master:Confirmation
MAC ID Service Code CAN ID
Byte0 Byte1
41B
0A 90
