DEVICE NET USER MANUAL
BEI IDEACOD SAS
Espace Européen de l’Entreprise
9, rue de Copenhague
B.P. 70044 Schiltigheim
F 67013 Strasbourg Cedex
Tél : +33 (0)3 88 20 80 80
Fax : +33 (0)3 88 20 87 87
Mail : [email protected]
Web : www.bei-ideacod.com
Hollow shaft (B)
* Edelstahl / Stainless steel
2
0
°
Ø63
20
72
Single-Turn=100 , Multi-Turn=112
1,3
3,3
Anla
gekante
an M
o
mentenstütze
Ø1
5
F7
15
23
Ш59 (Ш61
)*
~32
Ш6,5-9
Schlüsselweite, wrench size=17
Ш3,2
63,5
20 20
Ш60
(lay-on ed
ge
torque sup
p
o
rt)
** Welleneinstecktiefe (hollow shaft depth)
Max. W ** = 30
Min. W ** = 15
Mounting instructions
The clamp ring may only be tightened if the
shaft of the driving element is in the hollow
shaft.
The diameter of the hollow shaft can be
reduced to 12mm, 10 mm or 8 mm by using an
adapter (this reducing adapter can be
pushed into the hollow shaft).
Allowed shaft movements of the drive element
are listed in the table.
axial radial
static ± 0,3 mm ± 0,5 mm
dynamic ± 0,1 mm ± 0,2 mm
Page 28 UME-OCD-D2 Version 05/04
