IM-pAC Getting Started Guide
www.camcoindex.com | www.destaco.com
Issue Number: 5
If the enable terminal is opened, the drive’s output is disabled and the motor will coast to
a stop. The drive will not re-enable for 1.0s after the enable terminal is closed again.
*Following a drive trip, opening and closing the enable terminal will reset the drive. If the
run forward or run reverse terminal is closed, the drive will run straight away.
**Following a drive trip and a reset via the stop/reset key, the enable, run forward or run
reverse terminals will need to be opened and closed to allow the drive to run. This
ensures that the drive does not run when the stop/reset key is pressed.
The enable, run forward and run reverse terminals are level triggered apart from after a
T5
Status relay - Drive ok (Normally open)
T6
Voltage rating
240Vac/30Vdc
Current rating
2A/6A (resistive)
Contact isolation
1.5kVac (over voltage category II)
Operation of contact
OPEN
AC supply removed from drive
AC supply applied to drive with drive in tripped condition
CLOSED
AC supply applied to drive with drive in a 'ready to run' or
'running' condition (not tripped)
Provide fuse or other over-current protection in status relay circuit.
WARNING
B1
Analog voltage output - Motor speed
Voltage output
0 to +10V
Scaling
0V represents 0Hz/rpm output
+10V represents the value in Pr 02 Maximum set speed
Maximum output current
5mA
Resolution
0.1%
B2
+24V output
Maximum output current
100mA
B3
Digital output - Zero speed
Voltage range
0 to +24V
Maximum output current
50mA at +24V (current source)
The total available current from the digital output plus the +24V output is 100mA.
NOTE
B4
Digital Input - Enable/Reset*/**
B5
Digital Input - Run Forward**
B6
Digital Input - Run Reverse**
B7
Digital Input - Local/Remote speed reference select (A1/A2)
Logic
Positive logic only
Voltage range
0 to +24V
Nominal threshold voltage
+10V
