DE-STA-CO IM-pAC AC Drive Getting Started Guide User Manual
Page 4

4
IM-pAC Getting Started Guide
www.camcoindex.com | www.destaco.com
Issue Number: 5
Rating Data ........................................................................35
Mechanical Installation .....................................................37
Electrical Installation ........................................................39
Power terminal connections ..................................................................39
Control terminals I/O specification .........................................................42
Keypad and Display ..........................................................46
Programming keys ................................................................................46
Selecting and changing parameters ......................................................47
Saving parameters ................................................................................48
Parameter access .................................................................................48
Parameters .........................................................................50
Parameter descriptions - Level 1 ...........................................................50
Parameter descriptions - Level 2 ...........................................................57
Parameter descriptions - Level 3 ...........................................................66
Diagnostic parameters ..........................................................................66
Diagnostics ........................................................................67
UL Listing Information ......................................................70
Common UL information (for IM-pAC size A and B) .............................70
9.2
Power dependant UL information ..........................................................70
