Parameter Description Value Units
Pr 01
Minimum set speed 0 Hz
Pr 02 Maximum set speed 60 Hz
Pr 03 Acceleration rate 1 0.1 s/100Hz
Pr 04
Deceleration rate 1 0.2 s/100Hz
Pr 05 Drive configuration 3:Pr
Pr 06 Motor rated current - A (from motor plate)
Pr 07 Motor rated full load rpm 0 RPM (always 0)
Pr 08 Motor rated voltage - V (from motor plate)
Pr 09 Motor rated power factor - (from motor plate)
Pr 10 Security status 2:L3
Pr 11 Start / stop logic select 2
Pr 12
Brake controller enable 0:dis
Pr 15 Jog reference 1.5 Hz
Pr 16
Analog input 1 mode
(terminal T2)
6:VoLt
Pr 17
Allow negative
references
OFF
Pr 18 Preset speed 1 50 Hz
Pr 19
Preset speed 2 0 Hz
Pr 20 Preset speed 3 0 Hz
Pr 21 Preset speed 4 0 Hz
Pr 22 Load display units Ld
Pr 23 Speed display units 0:Fr
Pr 24 Customer defined scaling 1
Pr 25 User security code 0
Pr 27
Power-up keypad
reference
0
Pr 28
Parameter cloning 0:no
Pr 29 Load defaults 0:no
Pr 30 Ramp mode select 3:FSt.Hv
Pr 31 Stopping mode select 1
Pr 32 Dynamic V to f select OFF
Pr 33
Catch a spinning motor
select
0
Pr 34 Terminal B7 mode select 0:dig
Pr 35
Digital output control
(terminal B3)
0:n=0
Pr 36
Analog output control
(terminal Bi)
0:Fr
Pr 37
Maximum switching
frequency
12 kHz
Pr 38 Auto-tune 0
Pr 39 Motor rated frequency - Hz (from motor plate)
Pr 40 Number of motor poles 2:4 pole
Pr 41 Voltage mode select 2:Fd
Pr 42
Low frequency voltage
boost
4
Pr 43 Serial comms baud rate 19.2
