IM-pAC Getting Started Guide
43
Issue Number: 5
www.camcoindex.com | www.destaco.com
Re
Sa
R
Me
ch
El
Ke
Par
D
UL
Li
0-20
: Current input 0 to 20mA (20mA full scale)
20-0
: Current input 20 to 0mA (0mA full scale)
4-20
: Current input 4 to 20mA with current loop loss (cL1) trip (20mA full scale)
20-4
: Current input 20 to 4mA with current loop loss (cL1) trip (4mA full scale)
4-.20
:Current input 4 to 20mA with no current loop loss (cL1) trip (20mA full scale)
20-.4
:Current input 20 to 4mA with no current loop loss (cL1) trip (4mA full scale)
VoLt
: 0 to 10V input
The above warnings also apply to the PCB edge connector for the optional Solutions
Modules. To allow a Solutions Module to be installed with an IM-pAC, a protective cover
must be removed to allow access to the PCB edge connector. See Figure 4-3 on page 38.
This protective cover provides protection from direct contact of the PCB edge connector by
the user. When this cover is installed and a Solutions Module fitted, the Solutions Module
provides the protection from direct contact by the user. If the Solutions Module is then
removed, this PCB edge connector becomes exposed. The user is required to provide
protection in this case, to protect against direct contact of this PCB edge connector.
WARNING
See Pr 05 on page 51 (Drive configuration) for terminal connection / set-up diagrams and
details.
NOTE
The digital inputs are positive logic only.
NOTE
The analog inputs are unipolar.
NOTE
T1
0V common
T2
Analog input 1 (A1), either voltage or current (see Pr 16)
Voltage: Current input
0 to 10V: mA as parameter range
Parameter range
4-20, 20-4, 0-20, 20-0, 4-.20, 20-.4, VoLt
Scaling
Input range automatically scaled to Pr 01 Minimum set
speed
/ Pr 02 Maximum set speed
Input impedance
200Ω (current): 100kΩ (voltage)
Resolution
0.1%
T3
+10V reference output
Maximum output current
5mA
T4
Analog input 2 (A2), either voltage or digital input
Voltage: Digital input
0 to +10V: 0 to +24V
Scaling (as voltage input)
Input range automatically scaled to Pr 01 Minimum set
speed
/ Pr 02 Maximum set speed
Resolution
0.1%
Input impedance
100kΩ (voltage): 6k8 (digital input)
Normal threshold voltage (as digital input) +10V (positive logic only)
