IM-pAC Getting Started Guide
www.camcoindex.com | www.destaco.com
Issue Number: 5
1.27
Drive parameter list for a 24Vdc brake motor
Parameter
Description
Value
Units
Pr 01
Minimum set speed
0
Hz
Pr 02
Maximum set speed
60
Hz
Pr 03
Acceleration rate 1
0.1
s/100Hz
Pr 04
Deceleration rate 1
0.2
s/100Hz
Pr 05
Drive configuration
3:Pr
Pr 06
Motor rated current
-
A (from motor plate)
Pr 07
Motor rated full load rpm
0
RPM (always 0)
Pr 08
Motor rated voltage
-
V (from motor plate)
Pr 09
Motor rated power factor
-
(from motor plate)
Pr 10
Security status
2:L3
Pr 11
Start / stop logic select
0
Pr 12
Brake controller enable
1:rEL
Pr 15
Jog reference
1.5
Hz
Pr 16
Analog input 1 mode
(terminal T2)
6:VoLt
Pr 17
Allow negative
references
OFF
Pr 18
Preset speed 1
60
Hz
Pr 19
Preset speed 2
0
Hz
Pr 20
Preset speed 3
0
Hz
Pr 21
Preset speed 4
0
Hz
Pr 22
Load display units
Ld
Pr 23
Speed display units
0:Fr
Pr 24
Customer defined scaling
1
Pr 25
User security code
0
Pr 27
Power-up keypad
reference
0
Pr 28
Parameter cloning
0:no
Pr 29
Load defaults
0:no
Pr 30
Ramp mode select
3:FSt.Hv
Pr 31
Stopping mode select
1
Pr 32
Dynamic V to f select
OFF
Pr 33
Catch a spinning motor
select
0
Pr 34
Terminal B7 mode select
0:dig
Pr 35
Digital output control
(terminal B3)
0:n=0
Pr 36
Analog output control
(terminal Bi)
0:Fr
Pr 37
Maximum switching
frequency
12
kHz
Pr 38
Auto-tune
0
Pr 39
Motor rated frequency
-
Hz (from motor plate)
Pr 40
Number of motor poles
2:4 pole
Pr 41
Voltage mode select
2:Fd
Pr 42
Low frequency voltage
boost
4
