Diagram for wiring switches to the IM-pAC control terminals (cover has been removed)
for cycling on demand using a limit swit ch, momentary start and inverter duty motor.
Index drive is in middle of dwell position see section 1.16 Indexer drive shown in middle
of dwell position diagram.
on page 9.
Pr 23
Speed display units 0:Fr
Pr 24 Customer defined scaling 1
Pr 25 User security code 0
Pr 27
Power-up keypad
reference
0
Pr 28 Parameter cloning 0:no
Pr 29
Load defaults 0:no
Pr 30 Ramp mode select 3:FSt.Hv
Pr 31 Stopping mode select 1
Pr 32
Dynamic V to f select OFF
Pr 33
Catch a spinning motor
select
0
Pr 34
Terminal B7 mode select 0:dig
Pr 35
Digital output control
(terminal B3)
0:n=0
Pr 36
Analog output control
(terminal Bi)
0:Fr
Pr 37
Maximum switching
frequency
12 kHz
Pr 38
Auto-tune 0
Pr 39 Motor rated frequency - Hz (from motor plate)
Pr 40 Number of motor poles 2:4 pole
Pr 41
Voltage mode select 2:Fd
Pr 42
Low frequency voltage
boost
4
Pr 43 Serial comms baud rate 19.2
Pr 44 Serial comms address 1
Pr 45 Software version 1.04
Pr 46
Brake release current
threshold
50
Pr 47
Brake apply current
threshold
10
Pr 48
Brake release frequency 1 Hz
Pr 49 Brake apply frequency 2 Hz
Pr 50 Pre-brake release delay 0 s
Pr 51 Post brake release delay 0 s
Parameter Description Value Units
