73
Trigger Source Internal, External, Manual
Phase Offset
Range 0 ° – 360 °
Resolution 0.1 °
Trigger Characteristics
Trigger Input
Input Level TTL compatible
Slope Rising or Falling, selectable
Pulse Width > 100 ns
Input Impedance > 5 kΩ, DC coupling
Maximum
Frequency
1 MHz
Input Latency < 300 ns
Trigger Output
Voltage Level TTL compatible
Pulse Width > 400 ns
Output Impedance 50 Ω
Maximum
Frequency
1 MHz
Modulation Characteristics
Amplitude Modulation
Carrier Sine, Square, Ramp, Arbitrary (except DC)
Source Internal, External
Modulation
Waveform
Sine, Square, Ramp, Noise, Arbitrary (2 mHz – 20 kHz)
Modulation Depth 0 % - 120 %
Frequency Modulation
Carrier Sine, Square, Ramp, Arbitrary (except DC)
Source Internal, External
Modulation
Waveform
Sine, Square, Ramp, Noise, Arbitrary (2 mHz – 20 kHz)
Frequency
Deviation
0 – 0.5*bandwidth, 10 µHz resolution
FSK
Carrier Sine, Square, Ramp, Arbitrary (except DC)
Source Internal, External
Modulation
Waveform
50 % duty cycle square waveform (2 mHz – 50 kHz)
ASK
Carrier Sine, Square, Ramp, Arbitrary (except DC)
Source Internal, External
Modulation
Waveform
50 % duty cycle square waveform (2 mHz – 50 kHz)
DSB-AM
Carrier Sine, Square, Ramp, Arbitrary (except DC)
Source Internal, External
