71
5 Specifications
Note: All specifications apply to the unit after a temperature stabilization time of 15
minutes over an ambient temperature range of 23 °C ± 5 °C. Specifications are subject to
change without notice.
Environmental Conditions:
This instrument is designed for indoor use and operated with maximum relative humidity of
95%.
Model 4052 4053 4054 4055
Channels 2
Frequency Characteristics
Sine 1 µHz – 5 MHz 1 µHz – 10
MHz
1 µHz – 25
MHz
1 µHz – 50
MHz
Square 1 µHz – 5 MHz 1 µHz – 10
MHz
1 µHz – 25 MHz
Triangle, Ramp 1 µHz – 300 kHz
Pulse 500 µHz – 5 MHz
Gaussian Noise (-3 dB) > 5 MHz > 10 MHz > 25 MHz > 50 MHz
Arbitrary 1 µHz – 5 MHz
Accuracy ± 50 ppm (90 days)
± 100 ppm (1 year)
Resolution 1 µHz
Arbitrary Characteristics
Built-in Waveforms 48 Built-in waveforms (includes DC)
Waveform Length 16,000 points / Ch
Vertical Resolution 14 bits
Sampling Rate 125 MSa/s
Minimum Rise/Fall
Time
7 ns (typical)
Jitter (pk-pk) 8 ns (typical)
Non-volatile memory
storage
10 waveforms
Output Characteristics
Amplitude Range Channel 1: 2 mVpp – 10 Vpp into 50 Ω, ≤ 10 MHz
2 mVpp – 5 Vpp into 50 Ω, > 10 MHz
4 mVpp – 20 Vpp into open circuit, ≤ 10 MHz
4 mVpp – 10 Vpp into open circuit, > 10 MHz
Channel 2: 2 mVpp – 3 Vpp into 50 Ω
4 mVpp – 6 Vpp into open circuit
Amplitude Resolution Up to 4 digits
Amplitude Accuracy
(100 kHz)
± (0.3 dB + 1 mVpp of setting value)
Amplitude Flatness ± 0.3 dB
