51
WARNING: Please stop repairing the components to be tested before the
test starts and keep a certain distance during the test.
3.6 Generic OBD II Functions
The OBD II Diagnostics function is a fast-access option that allows you to
carry out a quick test on the engine system of OBD II vehicles.
3.6.1. General Procedures
To access the ODBII diagnostics functions, please follow these steps:
1. Power up the screen to display the home screen (Figure 1.8).
2. Click on the OBD II icon. The scan tool displays a System Status screen
that describes the basic status of the vehicle.
3. Click on OK, and wait for the Diagnostic Menu to appear.
Figure 3.46: OBD II-Diagnostic Menu Screen
4. Select a function by clicking on it once.

System Status

Read Codes

Erase Codes

Live Data

Freeze Frame
