Autel MaxiDAS DS708 User Manual
Page 51
45
Temporarily shades the Save function button.
Automatically records the frames of data that occur after clicking on the
button.
NOTE: You can record any number of files as long as they fit on the free
space on the SD card. To stop recording, just click on the Stop function
button.
3. When the recording stops, continue viewing live data or use the ESC
button to return to previous screens.
4. To view the saved data file, refer to Section 4.2 Playback.
3.
To Top
The To Top function allows you to move a selected data line to the top of the
Live Data screen.
Figure 3.36: Live Data Screen-To Top Function
To move a data line to the top of the screen, please follow these steps:
1. With the Live Data screen displayed, select the line to move.
2. Click on the To Top function key. The selected line moves to the top of
the screen.
3. Repeat steps 1 and 2 for each line to move.
4.
The Print function on the Live Data screen menu allows you to print the data
