55 745-419-B0-001 Rev. A (11/2013)
3.9.9 Test Results
Below the test control buttons is a text area that displays the results of the ping test. Any issues
with the parameters will be displayed at the top of the results box. During a test, the Web
page will automatically refresh to show the current results. This refresh stops once the test is
completed.
The results area permits the user to select results and copy them for pasting into another
program. This is accessed by standard Web browser methods: either left-clicking in the box and
pressing Ctrl-a (select all), or right-clicking in the box and clicking “Select all”, or by simply using
the mouse cursor, and selecting those lines of interest. Copy is done via standard commands
used on the system in use (e.g., under Windows, use Ctrl-c to copy.) Fig. 5-14 shows a typical set
of Ping results.
Fig. 3-14, Ping Results
Button Description
Start Test
Starts the ping test. Each of the values provided in the input fields is evaluated for validity.
If the host name field is blank, the test will not proceed. (The exception is leaving it blank when a
previous name had been entered, in which case that name will be used.)
Range checking is applied to the parameters. Any parameter out of range will be ignored, and the
default value used.
Any issues with the parameters will be displayed at the top of the results box.
When the test is started, the Web page will begin to automatically refresh. Also, a message will be
displayed:
Ping in use from ; pings xxx; size yyy; timeout zzz seconds,
indicating the parameters actually in use. This message is also in the text box.
Abort Test Stops any ping test currently in progress.
Clear Results Clears the results window.
3.0 Configuration and Operation, continued
3.9.8 Controlling the Ping Test
The Ping Test is controlled by the following buttons.
Table 3-7, Ping Command Controls
Pinging from Cable Modem: pings 25; size 64 bytes; timeout 5 seconds
Pinging cms-pit.cheetah.com ...
Reply from 172.16.0.11: bytes= 64 seq=0 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=1 time=0 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=2 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=3 time=0 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=4 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=5 time=0 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=6 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=7 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=8 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=9 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=10 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=11 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=12 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=13 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=14 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=15 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=16 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=17 time=0 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=18 time=0 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=19 time=0 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=20 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=21 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=22 time=10 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=23 time=0 ms TTL=62
Reply from 172.16.0.11: bytes= 64 seq=24 time=0 ms TTL=62
Ping statistics:
Pings sent: 25 (1 per second); Replies received: 25 (1 per second)
Bytes sent: 1600 (66 per second); Bytes received: 1600 (66 per second)
25 replies passed verification (0 failed)
Min time: 0 ms; Max time: 10 ms; Avg time: 6 ms; Total time: 24230 ms
