35 745-419-B0-001 Rev. A (11/2013)
Legend
1 RF Cable (customer supplied)
2,3 Battery Sense Wire Harness
4
Interface Cable Assembly -
EDH4 to CPR with Level 2 Card
5 Battery Heater Mat Control Cable
6 Ethernet Cable (optional)
7 Surge Protector with Ground Block
8 Tamper Wire Harness
Fig. 2-18, Input and Output Connections, Lectro CPR
2.0 Installation, continued
2.7 Lectro CPR Power Supply with Existing Level 2 Card, continued
 


 
 
 
 
   
   
 







 










  
  



 LECTRO









A/B [C/D] NEG
Pin 1
4A
POS
NEG
A/B [C/D] NEG
Pin 1
Vbatt 3
A [C] 36V Pin 4
Vbatt 2
A [C] 24V Pin 3
Vbatt 1
A [C] 12V Pin 2
Vbatt 4
A [C/D] 48V Pin 8
NEG NEG NEG
3A 2A 1A
1
2
3
4
5 6
7
8
FRONT
BACK
To strings 3 and 4
