3.2 4i Shelf Systems (No Battery Charger)
The 4i systems, with up to 4 AIM1500 modules per shelf, do not have an integrated 48V charger. The
following table shows available configurations: refer to the section in the last column for more details.
System Part
Number
Max AC
output VA
Max AC
output power
AC Input and
Output voltage
# of 4
Inverter
shelves
Max # of
AIM1500
modules
Reference
0260012-201 6kVA 4.8 kW
120 V single phase
1 4
Section 3.5
0260012-203 12kVA 9.6 kW 2 8
0260012-202
(no LCD)
" " " " " "
0260012-204 12kVA 9.6 kW 120/208 V 2-phase
or
120/240 V split phase
2 8
Section 3.6
0260012-206 24kVA 19.2 kW 4 16
0260012-205 18kVA 14.4 kW 120/208 V 3-phase 3 12 Section 3.7
3.3 3i+1R Shelf Systems (Integrated Battery Charger)
3i+1R Shelf Systems have 1 rectifier per shelf and up to 3 inverters per shelf.
System Part
Number
Max AC
output VA
Max AC
output power
AC Input and
Output voltage
# of 3i+1R
shelves
Max # of
AIM1500
modules
Reference
0260011-101 4.5kVA 3.6 kW
120 V single phase
1 x 3i+1R shelf 3
Section 3.5
0260011-102 9kVA 7.2 kW 2 x 3i+1R shelves 6
0260011-104
10.5kVA 8.4 kW 1 x 3i+1R shelf
plus 1 x 4i shelf
7
0260011-103 9kVA 7.2 kW
120/208 V 2-pole
or
120/240 V split
phase
2 x 3i+1R shelves 6
Section 3.6
0260011-106 18kVA 14.4 kW 4 x 3i+1R shelves 12
0260011-107
21kVA 16.8 kW 2 x 3i+1R shelf
plus 2 x 4i shelf
14
0260011-105 13.5kVA 10.8 kW 120/208 V 3-phase 3 x 3i+1R shelves 9 Section 3.7
3.4 System Spares
See "Table J — Spare Parts" on page 69.
