7 Parameters
610.00260.40.000 · 05.2014 48 / 74 © Gardner Denver Deutschland GmbH
4.021/4.051 AIx Norm. Low Unit: %
Relationship to
parameter: Parameter HB:
S. xy
Transfer
status:
2
min: 0 Intrinsic value
(to be en-
tered!)
max: 100
Def: 0
Specifies the minimum value of the analogue inputs as a per-
centage of the final range value.
Example:
0... 10V or 0... 20 mA = 0 %... 100%
2... 10V or 4... 20mA = 20%... 100%
4.022/4.052 AIx Norm. High Unit: %
Relationship to
parameter: Parameter HB:
S. xy
Transfer
status:
2
min: 0 Intrinsic value
(to be en-
tered!)
max: 100
Def: 100
Specifies the maximum value of the analogue inputs as a per-
centage of the final range value.
Example:
0…10V or 0…20mA = 0%…100%
2…10V or 4…20mA = 20%…100%
4.023/4.053 Alx backlash Unit: %
Relationship to
parameter: Parameter HB:
S. xy
Transfer
status:
2
min: 0 Intrinsic value
(to be en-
tered!)
max: 100
Def: 0
Backlash as percentage of final range value of the analogue
inputs.
4.024/4.054 AIx filtering time Unit: s
Relationship to
parameter: Parameter HB:
S. xy
Transfer
status:
2
min: 0,02 Intrinsic value
(to be en-
tered!)
max: 1,00
Def: 0
Filtering time of the analogue inputs in seconds.
4.030/4.060 Alx function Unit: Integer
Relationship to
parameter: Parameter HB:
S. xy
Transfer
status:
2
min: 0 Intrinsic value
(to be en-
tered!)
max: 1
Def: 0
Function of the analogue inputs ½.
0 = analogue input
1 = digital input
