ES3610/11 User Guide Section 4: VN-GLIMPSE VIEWER
I447GB issue 6 Page 37
Source Connection and Disconnection
To connect to a Source using the Channel List…
Double-click the required source name or IP Address in the Channel List.
Alternatively, highlight the required source (single-click) then click the Connect button on the
toolbar.
HINT: If the required source is not displayed, try refreshing the list by clicking the Refresh button
on the toolbar, or choosing Refresh Channel List from the View menu, or pressing F5 on the
keyboard.
To connect to a Source using the Connect dialog box…
From the File menu choose Connect To. The following dialog will appear:
Enter either the IP Address or Name of the source that you want to connect to.
HINT: The drop-down list shows the most recently entered or selected sources. If required, you
can select one of these.
Click the Connect button.
To disconnect from a source…
Click the Disconnect button on the toolbar.
Alternatively, choose Disconnect from the File menu.
