Section 1: Introduction ES3610/11 User Guide
Page 14 I447GB issue 6
Accessories
Supplied Accessories
In addition to this User Guide, the RGB ADAPTER is supplied with the following accessories. If any of
these items is missing or damaged, please contact your Electrosonic dealer immediately:
Item Qty Re-order Code
12V Power Supply Unit (PSU)
Note: ES3610-P has a square-style connector; ES3611-P
has a round-style connector. 1 ES3610-P
ES3611-P
Mains Cord for PSU (with 3-pin ‘Edison’ plug)
For use in the USA.
1 CA4291
Mains Cord for PSU (bare-ended)
For use in Europe and all other countries.
1 CA429
Mouse/Keyboard Cable (2 metre PS/2 to PS/2) 2
Digital Monitor Cable (2 metre DVI-D to DVI-D) 1
Analog Monitor Cable (2 metre 15-pin HD-type to DVI-A) 1
DVI-A to 15-pin HD Adapter 1
Clip-on Ferrite*
For supplied Monitor Cable – see Important Note below. 1
Digital Cable Kit:
ES3611-CD
Analog Cable Kit:
ES3611-CA
Software Disc
Containing VN-GLIMPSE Setup Utility, VN-GLIMPSE
VIEWER and ADMINISTRATOR, plus full documentation.
1 M20046
* IMPORTANT NOTE: Whether you are using the Digital or Analog Monitor Cable,
it must be fitted with the Clip-on Ferrite. Position the ferrite nearest to the end of the
cable that connects to the DVI-I IN connector on the VN-GLIMPSE RGB ADAPTER.
Refer to the connection diagrams on pages 24 & 25.
Optional Accessories
The following optional accessories are also available for use with the RGB ADAPTER – these must
be ordered separately from your Electrosonic dealer:
Item Order Code
Rack Mounting Kit
A kit that allows one or two ES3610/11 units to be installed in a
19inch equipment rack. Full instructions are included with the kit.
ES3611-RM
