Mains power cord (for psu), Power-up procedure – Extron Electronics ES3610_11 User Guide User Manual
Page 20
Section 2: Installation
ES3610/11 User Guide
Page 20
I447GB issue 6
Mains Power Cord (for PSU)
The mains PSU is equipped with a 3-pin (male) type mains connector which requires a power cord
fitted with a corresponding 3-pin IEC320 (female) connector.
Two power cords are supplied with the PSU, each having a different termination; you must use the
lead appropriate for your country:
In...
Use the...
Re-order Code
USA and Canada
cord fitted with the 3-pin
American-style ‘Edison’ plug.
CA4291
UK, Europe and all
other countries
unterminated cord and fit a
suitable plug as described on
page 21.
CA429
WARNING: Do not allow anything to rest on the mains power cord.
Power-up Procedure
You must always ensure that the RGB ADAPTER is powered-up at the same time as the source
computer or slightly before.
Powering the RGB ADAPTER after the source computer may result in the source computer not
correctly detecting the mouse, keyboard and/or monitor.
