ES3610/11 User Guide Section 2: Installation
I447GB issue 6 Page 23
Connecting to a Computer
The RGB ADAPTER is compatible with both digital (DVI) and analog graphics signals. The unit is
provided with the necessary additional cables that you will require.
For a Digital Source…
Use the following cables (replacement kit no. ES3610-CD)
and refer to the connection diagram on page 24.
•
Mouse/Keyboard Cable (PS/2 to PS/2) (2 off),
• Digital Monitor Cable (DVI-D to DVI-D).
For an Analog Source…
Use the following cables (replacement kit no. ES3610-CA)
and refer to the connection diagram on page 25.
• Mouse/Keyboard Cable (PS/2 to PS/2) (2 off),
•
Analog Monitor Cable (15-pin Hi-Density D-type to DVI-A), plus
• DVI-A to 15-pin Hi-Density D-type Adapter
IMPORTANT NOTES
The VN-GLIMPSE RGB ADAPTER does not provide Analog-to-Digital or Digital-to-Analog conversion
via its monitor connections. A digital source must use a digital monitor and an analog source must use
an analog monitor.
Disconnecting and reconnecting PS/2 cables to a computer that is already switched on may cause
loss of mouse/keyboard control or cause the computer to ‘freeze’. It is recommended, therefore, that
the connections are made while the computer is powered-down. See also ‘Power-up Procedure’ on
page 20.
If you use a monitor cable or adapter other than that provided with the RGB ADAPTER you must
ensure that all pins are properly interconnected, otherwise the computer graphics card or monitor may
not operate correctly.
