Programmer’s Guide, cont’d
MVX VGA A Matrix Switchers • Programmer’s Guide 4-12
PRELIMINAR
Y
Command/response table for SIS commands (continued)
Command ASCII command
(host to switcher)
Response
(switcher to host)
Additional
description
Information requests
Information request I V
X2)
X
X2!
•A
X2)
X
X2!]
Request part number N X2@] See appendix A for part
numbers.
N There are two separate sets of Extron firmware on which the switcher can report: the controller firmware, which is the
overall control firmware, and the latest optional Extron firmware update, which is available at www.Extron.com.
Query controller firmware
version Q X1!]
Example: Q 1.23
] The factory-installed
controller firmware version
is 1.23 (sample value only).
Query controller firmware
version (verbose) 0Q X1!
-
X1@
-
X1@] Provide a detailed status of
the MVX controller firmware
and any firmware upgrade.
• The firmware that is
running is marked by an
asterisk (*).
• A caret (^) indicates that
the firmware has a bad
checksum or an invalid
load.
• ?.?? indicates that
firmware is not loaded.
Response description: Controller firmware version-updated firmware version
]
Example: 0q
Meaningless data
for this switcher model
Response:
Description
MVX firmware version
n .nn-1.00(1.06-16x16 Series -Wed, 22 Feb 2006 00:00:00 GMT)-1.00*(1.06-16x16 Series -Thu, 16 Mar 2006 16:39:21 GMT)
Updated firmware version
* indicates the version running Upload date and time
Request system status S X2#
•
X2#
•
X2#
•
X2#
•
X2# • X2$]
Response description: +3.3V •+5V•-5V•+15V•-15V•temperature (degrees fahrenheit)
]
Example:
3.29•5.04•-5.14•15.27•-15.15•120.20
-15V power system at -15.15V
Temperature 120.20 degrees 3.3V power system at 3.29V
