Operation, cont’d
MVX VGA A Matrix Switchers • Operation 3-4
PRELIMINAR
Y
Control buttons
d
Enter button and/or LED — The Enter button and LED have three primary
functions (•) and four secondary functions (❏):
• Saves changes that you make on the front panel. To create a simple
configuration:

Specify RGBHV, audio, or both (see I/O selection buttons [ h ] and
[ i ]).

Press the desired input button ( a ).

Press the desired output button(s) ( b ).

Press the Enter button.
• Indicates that a potential tie has been created but not saved.
• Indicates that a global preset has been selected to be saved or recalled but
that the preset action has not been accomplished.
❏ With the Preset, View, and Esc buttons, selects Serial Port Configuration
mode. See “Selecting the rear panel Remote port protocol and baud rate”
on page 3-38.
❏ Selects 9600 baud for the Remote port in Serial Port Configuration mode.
See “Selecting the rear panel Remote port protocol and baud rate” on
page 3-38.
❏ Indicates that the Remote port is set to 9600 baud in Serial Port
Configuration mode. See “Selecting the rear panel Remote port protocol
and baud rate” on page 3-38.
❏ With the RGBHV and Audio buttons, select front panel security lockout
mode 2 or toggle between mode 0 (unlocked) and mode 2. See “Setting
the front panel locks (Executive modes)” on page 3-36.
e
Preset button and/or LED — The Preset button and LED have two primary
functions (•) and three secondary functions (❏):
• Activates Save Preset mode to save a configuration as a preset and Recall
Preset mode to activate a previously-defined preset.
• Blinks when Save Preset mode is active and lights steadily when Recall
Preset mode is active.
❏ With the Enter, View, and Esc buttons, selects Serial Port Configuration
mode. See “Selecting the rear panel Remote port protocol and baud
rate” on page 3-38.
❏ Selects 19200 baud for the Remote port in Serial Port Configuration mode.
See “Selecting the rear panel Remote port protocol and baud rate” on
page 3-38.
❏ Indicates that the Remote port is set to 19200 baud in Serial Port
Configuration mode. See “Selecting the rear panel Remote port protocol
and baud rate” on page 3-38.
