TLP 350CV Reset Mode Summary
Mode Mode Activation Result Purpose/Notes
Use Factory Firmwar
e
1 Hold the reset button while
applying power.
NOTE: After a mode 1 reset, update the
TLP 350CV firmware to the latest
version. DO NOT operate the
firmware version that results from
this mode reset.
The TLP 350CV reverts to the
factory default firmware.
event scripting does not start if
the TLP 350CV is powered on
in this mode. All user files and
settings (drivers, adjustments, IP
settings, etc.) are maintained.
NOTE: If you do not want to update the
firmware, or performed a mode 1
reset by mistake, cycle power to
the TLP 350CV to return to the
firmware version running prior to
the reset.
This mode reverts to the
factory default firmware
version if incompatibility
issues arise with user-loaded
firmware.
NOTE: User-defined web pages may
not work correctly if using an
earlier firmware version.
Run/Stop
Events
3 Press and hold the Reset button
until the Power LeD blinks
once (3 sec.), then release and
within 1 second press Reset
momentarily (<1 sec).
NOTE: Nothings happens if the
momentary press does not occur
within 1 second.
Toggles events on or off. Useful for troubleshooting
Reset all
IP Settings
4 Press and hold the Reset button
for about 6 sec. until the Power
LeD blinks twice (once at 3 sec.,
again at 6 sec.), then release
and within 1 second press
Reset momentarily (< 1 sec.).
NOTE: Nothing happens if the momentary
press does not occur within 1
second.
z enables ARP capability.
z Set the IP address to
192.168.254.254 (default).
z Sets the subnet mask to
255.255.0.0 (default).
z Sets the gateway address to
0.0.0.0 (default).
z Sets port mapping back to
default.
z Turns DHCP off.
z Turns events off.
enables setting IP address
information using ARP and
MAC address.
Reset to
Factory Defaults
5 Press and hold the Reset button
for about 9 sec. until the Power
LeD blinks three times (once at
3 sec., again at 6 sec., again
at 9 sec.), then release and
within 1 second press Reset
momentarily (< 1 sec.).
NOTE: Nothing happens if the momentary
press does not occur within 1
second.
Performs a complete reset to
factory defaults, except for
firmware:
z Does everything mode 4
reset does.
z Removes button/touch
panel configurations.
z Resets all IP options.
z Removes scheduling
settings.
z Removes/clears all files from
the TLP 350CV.
Useful to start over with
configuration and/or
uploading, and to replace
events.
39 TLP 350CV • Reset Modes and Button Replacement
