Reset Modes
z
z
z
LED
Reset
Menu
Figure 26.
Reset Buttons
The modes are initiated by pressing the reset button. Using
a paper clip, push through the reset access hole on the right
side of the faceplate as shown below.
NOTE: The access holes are very small. Take care when
pressing the reset button to avoid scratching the
faceplate.
The successful completion of a reset is indicated by four
flashes of the reset LeD.
The TLP 350CV reset modes are initiated by pressing the
reset button on the front panel. See the table on the
following page for details.
Reset Modes
The TLP 350CV has four reset modes that correspond to four of the five
reset modes for the IP Link controllers.
TLP 350CV • Reset Modes, Button Replacement
38
