Extron Electronics TLP 350CV Installation User Manual
Page 30
z
Open an Existing Project — Clicking OK opens a dialog box that allows you to
navigate to an existing project for modification.
Figure 14.
GUI Configurator Dialog Box to Open an Existing Project
Navigate to the existing file and select it. A preview with information about the file
appears in the pane on the right.
If you will be working on the project, leave the “Open as read-only” box
unchecked.
Click Open to open the file. The project will open in GUI Configurator.
z
Download an Existing Project from a Panel — Clicking OK opens a dialog box
that allows you to download a file that has been uploaded to a panel.
Figure 15.
GUI Configurator Download Project Dialog Box
In the dialog box that opens, enter the IP address of the panel and use the Browse
button to navigate to a folder where the file will be saved.
Check “Open the project” and, “Close Download Manager”.
Click on OK. The project will be downloaded to your computer and will open in GUI
Configurator.
TLP 350CV • Configuration Software
24
