Volume Control
The Volume Control menu allows the user to adjust the
maximum volume of the sound, individual volume of
button click feedback, and audio playback. Pressing main
returns you to the main setup screen.
Master Volume
Master volume defines the maximum volume for all
playback. All other volume settings will be scaled in
proportion. If the master volume is set at 50% of full
volume and the click volume is also set at 50% of its full
volume, the maximum volume for the click playback will be
50% of 50%, or 25%. Adjust the master volume from 0 to
255 by pressing the Dn or Up buttons.
Click Volume
Click volume provides audio feedback of button presses
including the side buttons and the touch panel buttons.
Adjust click volume from 0 (min) to 255 (max) by pressing
the Dn or Up buttons.
Sounds Volume (not available on
TLP 350CV)
Sounds volume provides audio level control when
monitoring a playback device, if connected. Adjust sound
volume from 0 (min) to 255 (max) by pressing Dn or Up.
Main
Dn Up
Dn Up
Dn Up
Master: 255
Click: 255
Sounds: 255
Main
Vol
Time
IP Exit
Down Up
Down
On On
Up
Sleep timer: 50000 Sec
Backlight: 073%
Auto
Backlight
Vid
LED
Backlight
Time (and Date)
The time tab also adjusts the date. Use the on-screen
buttons to set the day, month, year, and the time in hours
and minutes.
NOTE: The Hours value uses the 24 hour clock. For
10 am, set hours to 10; for 10 pm, set hours
to 22.
when attached to a controller, the panel synchronizes its
time settings, Greenwich Mean Time (GMT) offset, and
DST. Values are also resynchronized each day at midnight
or by pressing the recessed front panel menu button for
10 seconds. Pressing main returns you to the main setup
screen.
Main
Dn Up
Dn Up
Dn Up
Dn Up
Dn Up
Month: 01
Day: 20
Year: 2010
Hours: 17
Minutes: 30
