Page 55
MLC 104 Plus Series • Software Setup
3-33
Step sixteen: build the Global Configurator file
Before a Global Configurator (GC) file is active in the
GlobalViewer interface, the GC file must be “built” and
uploaded to a GlobalViewer host device.
The “build” process compiles all of the configuration data you
have entered into the GC file for each A/V network device.
The upload process delivers the built (compiled) file to the
GlobalViewer host device.
To initiate a “Build (all)” process:
1
.
Click Build > Build All Configurations...
or
click the Build All Configurations icon.
A Please Wait. Building Configuration(s)... dialog box
opens and displays a progress bar while the GC file is
being built.
