MLC 104 Plus Series • Software Setup
3-9
Step four: define the location of the new device
(IP models only)
Global Configurator allows you to keep track of the devices on
your audio/video network by creating a custom tree of folders
in which you can place and organize your audio/video devices.
This GlobalViewer Tree can be up to eight levels deep and have
multiple folders in each level.
To move your newly added device to a location folder, with the
Add Device dialog box still open:
1
.
Click the New Location folder icon in the GlobalViewer
Tree window. You can create up to eight levels of location
folders.
2
.
Enter a unique location name for the new folder and keep
the new location folder selected.
3
.
Click OK. The new device is added to the selected location
folder and the Add Device dialog box closes.
