MLC 104 Plus Series • Software Setup
Software Setup, cont’d
3-26
2
.
Select an available control module.
3
.
Click the Add (right arrow,
) button.
The new control module is displayed in the Control
Module Summary field and in the IP Link Tree window.
4
.
Select the newly assigned control module's Address in the
IP Link Tree window.
5
.
Select the desired button on the control module and add
button operations as described in “Step eleven: configure
the front panel.”
