Page 19
MLC 104 Plus Series • Hardware Setup
2-7
Front Panel Host Configuration Port
A 2.5 mm mini stereo jack the provides an RS-232 connection for
configuration and control.
Use Extron configuration cable part #70-335-01 (9-pin D female
to 2.5 mm TRS) to connect a control PC to this port.
N
The MLC 104 Plus (units without a LAN connection) can
be configured only by this method.
CONFIG
DISPLAY
VOLUME
MLC 104 IP PLUS
ON
VCR
DVD
PC
OFF
1
2
3
4
Front Panel
Front Panel Host Configuration Port
