Page 28: Software setup, cont’d
MLC 104 Plus Series • Software Setup
Software Setup, cont’d
3-6
Step three: add a device and set up its connection
For IP models
For IP models, obtain the following information from your
network administrator:
• IP address / hostname
• gateway IP
• subnet
• Telnet port
• web port
• passwords
1
.
Select MLC 104 IP Plus Series from the IP Link Device
drop-down list.
2
.
Enter an IP Address in the Name/IP Address field (or
leave the default address).
3
.
Enter a unique Display Name.
4
.
Click Make this device a GlobalViewer Host (if desired).
5
.
Click the Advanced button. This opens additional Add
Device screen options and changes the Advanced button
to read Basic. If you wish to return to the basic screen
options, click the Basic button.
