Installation, cont’d
MediaLink Controllers • Installation 2-12
POWER
A B
MLS100Series
Switcher
MLC/RS-232
Power Port
A B C D E A B C IR
Display/Source Control Extron Switcher Control Relays IR / RCM
RS-232 D E A B C A B D 1A 1B 2A 2B 3A 3B 1 2 3 4 5 6 Tally Out MLS/Power
33-644-01 A 07 01 Pr
inted in the USA
MLC 206 Bottom Panel
MLS 103 V
Rear Panel
3 1 2
OUTPUT INPUTS
MLS 103 V
L R
A B
L R L R L R 1 2 3 L R 4 AUX/MIX MONO AUDIO INPUTS OUT CONTROL/ POWER
12V .5A MAX
Ground ( )
+12VDC input
+12VDC
Ground ( )
Transmit (Tx)
B Receive (Rx)
A
Transmit (Tx)
Receive (Rx) B
A
Connecting an MLC 206
to a MediaLink
VersaTools Switcher and an external power supply
NOTE You must connect a
ground wire between
the MLC and MLS.
MLC 206's
MLS/Power
Port
NOTE If you use cable that has a
drain wire, tie the drain wire
to ground at both ends.
A B
MLS / Power
Ground all devices
External
Power Supply
(12VDC, 1A max.)
External
Power Supply
250 ft
(76.2 m)
max.
