ISM 482 Integrated Scaling Matrix Switcher • Reference Information 74
Cables and Connectors
When using signals with a scanning frequency of 15-125 kHz and running distances of 100
feet or more, use high resolution BNC cables to achieve maximum performance.
Bulk cable
Extron Part
RG6/Super High Resolution Cable
Part Number
RG6 bulk , 500’ (150m), single conductor 22-098-02
RG6-1 bulk , 1000’ (300m), single conductor 22-098-03
MHR-5 Cable (Non-plenum) Part Number
MHR-5 bulk, 500’ (150m) 22-020-02
MHR-5 bulk, 1000’ (300m) 22-020-03
MHR-5p (Plenum) Cable Part Number
MHR-5P bulk, 500’ (150m) 22-103-02
MHR-5P bulk, 1000’ (300m) 22-103-03
Assorted connectors
BNC Connectors Part Number
BNC male, mini HR crimp connectors, qty. 50 100-250-01
BNC male RG6 crimp connectors, qty. 50 100-260-01
Pre-cut cables
MHR-5 cable is used for RGBHV cable runs. It can also be used for composite video,
S-video, or RGsB. All Extron BNC cables have male connectors on both ends. A plenum
version of the MHR cable is also available.
MHR-5 Cable Part Number
MHR-5 BNC (6’ /1.8 meters to 300’ /90.0 meters) 26-260- xx
NOTE: Bulk cable in lengths up to 5000 feet (1524 meter) rolls is available with
or without connectors.
Button Labels
Eight sets of button labels are provided on the next page. If desired, cut them out of the
manual, write the applicable button information in each button area, and place them in the
switcher’s label window.
