ISM 482 Integrated Scaling Matrix Switcher • Operation 24
User presets are recalled using the Input buttons. See Recalling a user preset , on
page 13, for instructions on recalling a user preset.
Erase Preset submenu
Select the output with the settings that you want to erase by pressing the desired Output
button.
Rotate either the Adjust or the Adjust knob while the Erase Presets submenu is active
to highlight (< >) one of three memory presets to erase or highlight N/A for no preset. Press
the Next button to erase the preset. Highlight N/A and press the Next button to exit without
erasing the settings.
Exit menu
From the Exit menu (see figure 22), press the Next button to return to the default display
cycle, or press the Menu button to return to the Video & Audio Configuration menu.
Menu
Next
Menu
Default
Cycle
Video & Audio
Configuration
Exit Menu
Press Next to Exit
User Presets
Figure 22. Exit Menu Flowchart
